Mineral Insulated Metal Sheathed Cable The Ultimate Choice for Industrial

Quick Details:

 Type: K/N/E/J/T/S/R/B

Place of Origin: Zhejiang, China (Mainland)

Accuracy: I-0.4%t, II-0.75%t, III-1.5%t

Core number: 2,3,4,6

Inorganic mineral insulating lead material: Ni, Cu

Insulator: 99.6% high purity MgO

Certificate:ISO9001, IATF16949, CE

Application: connecting with thermocouple and instrument machine

Sheath material: 0Cr18Ni10Ti, SS304S,SS316L,SS316, Cu

Sheath Dia(mm):  φ3.0, φ4.0, φ6.0, φ8.0

Type for Sheath Wire Type K:

Different temperature measuring media and service conditions have an impact on the service life and temperature range of armored thermocouples, the data in the table is only recommended data.

Accuracy for Sheath Wire Type K

About this product:

Mineral insulated thermocouple cables are specialized cables used for temperature measurement in extreme environments.

A thermocouple temperature probe is a type of temperature sensor that uses the thermoelectric effect to measure temperature. Here’s a detailed overview of thermocouples, their construction, working principle, types, applications, and considerations:

Overview
Definition: A thermocouple temperature probe consists of two different metal wires joined at one end, which generates a voltage that corresponds to temperature differences. This voltage can be measured and converted into a temperature reading.

Construction
Wires: The probe is made of two different conductive metals (commonly copper, nickel, chromel, alumel, etc.) that form a junction.
Junction: The point where the two wires are joined is called the measuring or hot junction. The other end of the wires is connected to a measuring device (cold junction).
Insulation: The wires are often insulated with materials that can withstand high temperatures, such as ceramic or fiberglass, depending on the application.
Sheath: The entire assembly may be encased in a protective sheath made of metal or ceramic, which protects the thermocouple from the environment.
Working Principle
Seebeck Effect: When the two different metals are joined together and exposed to a temperature gradient, a voltage (thermoelectric voltage) is produced at the junction. The magnitude of this voltage relates to the temperature difference between the hot junction and the cold junction.
Measurement: The voltage generated is measured and converted into temperature using calibration data specific to the type of thermocouple.

Applications :

• Solid waste incinerators
• Sintering powdered metals
• Firing ceramic materials
• Gas or oil fired furnaces
• Fuel fired heat exchangers
• Box furnaces
• Nuclear or hydrocarbon based energy plants
• And many more...

• Sheath cables are used in various applications, including:
• Residential wiring
• Commercial electrical systems
• Industrial machinery
• Power distribution
• Outdoor installations
• Heavy-duty equipment
• Environmental Resistance:
• Many sheath cables are designed to resist moisture, chemicals, UV radiation, and temperature fluctuations, making them suitable for a variety of environments.
• Considerations When Selecting Sheath Cables:
• Application Requirements: Choose the type of sheath cable based on the specific application, considering factors like mechanical protection, environmental exposure, and electrical requirements.
• Compliance with Standards: Ensure that the cable meets relevant electrical codes and safety standards for your region (e.g., NEC in the United States).
• Voltage Rating: Verify that the cable's voltage rating is appropriate for your application.
• Installation Method: Consider how the cable will be installed (e.g., conduit, direct burial, etc.) and choose a sheath type that suits that installation method.
• In summary, sheath cables are essential components in electrical installations, providing protection, insulation, and flexibility for a wide range of applications.
