Mineral Insulated Metal Sheathed Cable for Thermocouple and Instrument Machine Connection

Quick Details:

 Type: K/N/E/J/T/S/R/B

Place of Origin: Zhejiang, China (Mainland)

Accuracy: I-0.4%t, II-0.75%t, III-1.5%t

Core number: 2,3,4,6

Inorganic mineral insulating lead material: Ni, Cu

Insulator: 99.6% high purity MgO

Certificate:ISO9001, IATF16949, CE

Application: connecting with thermocouple and instrument machine

Sheath material: 0Cr18Ni10Ti, SS304S,SS316L,SS316, Cu

Sheath Dia(mm):  φ3.0, φ4.0, φ6.0, φ8.0

Type for Sheath Wire Type K:

Different temperature measuring media and service conditions have an impact on the service life and temperature range of armored thermocouples, the data in the table is only recommended data.

Accuracy for Sheath Wire Type K

About this product:

Thermocouple Connections:

MI cables are commonly used to connect thermocouples to temperature measurement devices in applications such as furnaces, kilns, and chemical processing plants.
Instrumentation:

Suitable for connecting various instruments in process control systems, including pressure, flow, and level sensors.
Oil and Gas Industry:

Employed in drilling operations, pipelines, and refineries to monitor temperatures in extreme environments.
Power Generation:

Used in turbines, boilers, and other critical components where precise temperature measurement is essential for safety and efficiency.
HVAC Systems:

Applied in heating, ventilation, and air conditioning systems for accurate temperature monitoring and control.
Installation Considerations:
Bending Radius: MI cables have a specified minimum bending radius that should be adhered to during installation to avoid damaging the insulation.
Termination Techniques: Proper crimping or welding techniques should be used to ensure reliable electrical connections at the thermocouple junctions.
Environmental Factors: Consideration of factors such as temperature, pressure, and chemical exposure is critical during the selection and installation of MI cables.

Applications :

• Solid waste incinerators
• Sintering powdered metals
• Firing ceramic materials
• Gas or oil fired furnaces
• Fuel fired heat exchangers
• Box furnaces
• Nuclear or hydrocarbon based energy plants
• And many more...

• Sheath cables are used in various applications, including:
• Residential wiring
• Commercial electrical systems
• Industrial machinery
• Power distribution
• Outdoor installations
• Heavy-duty equipment
• Environmental Resistance:
• Many sheath cables are designed to resist moisture, chemicals, UV radiation, and temperature fluctuations, making them suitable for a variety of environments.
• Considerations When Selecting Sheath Cables:
• Application Requirements: Choose the type of sheath cable based on the specific application, considering factors like mechanical protection, environmental exposure, and electrical requirements.
• Compliance with Standards: Ensure that the cable meets relevant electrical codes and safety standards for your region (e.g., NEC in the United States).
• Voltage Rating: Verify that the cable's voltage rating is appropriate for your application.
• Installation Method: Consider how the cable will be installed (e.g., conduit, direct burial, etc.) and choose a sheath type that suits that installation method.
• In summary, sheath cables are essential components in electrical installations, providing protection, insulation, and flexibility for a wide range of applications.

Product Pictures:

Company Information:

A. Main Products

B. Package

We add heat shrink tubing and plastic film to make sure high insulated resistance.

Except marking notes, we also have pass card and test report for every coil cable.

C. Mi cable Production line

We have high - quality professional products, as well as advanced product lines and equipments. All of the products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.Along the increasing market demands, we continuously satisfy customers by updating products to improve prouduction systems, improve quality.

Order Notice:

1. Accurate quotation.

2. Confirm the price, trade term, lead time, payment term etc.

3. LEADKIN sales send the Proforma Invoice with LEADKIN seal.

4. Customer arranges the payment for deposit and sends us bank slip.

5. Middle Production-send photos to show the production line which you can see your products in . Confirm the estimated delivery time again.

6. End Production-Mass production products photos.

7. Clients make payment for balance and LEADKIN ships the goods. Inform the tracking number and check the status for clients.

8. The order is finished perfectly when you receive the goods and get satisfied with them .

9. Feedback to LEADKIN about Quality , Service, Market Feedback & Suggestion. And we will do better .
